AVM-MP500

Give your customers the flexibility to pay any way they choose. The MP-500 provides an all-in-one solution for magnetic swipe, contact, and contactless operations for unattended automated machines. A universally certified solution, the MP-500 utilises the latest technology so cashless vending machine operators are able to accept all forms of payment with the added benefits of easy installation, clearance, monitoring, and management.

SKU: AVM-MP500 Category: Tags: , , , ,

Part of a Complete Cashless Payment

The Mp-500 is one arm of a complete cashless payment solution. The system seamlessly integrates with telemetry, cashless clearance, monitoring, management, and business analytics offerings to facilitate a full service vending payment solution that is secure, durable, and reliable.

Communicate with your Consumers

Communicating with users has long been a challenge for operators of unattended cashless vending machines. The MP-500 enables voice interaction with your consumer in the local language. Additionally, two languages can be displayed to better facilitate consumer interaction.

Plug and Play

The Mp-500 is easy to install and use and is compatible with all automated machine standards. AVM takes care of all software updates remotely to ensure that your devices benefit from the latest technology and are up to date with payment standards and requirements.

Supported Payment Schemes
  • Contact Card: EMV Level 1 + Level 2 – Certified
  • Contactless: EMV Level 1 – Certified
  • Contactless: EMV Level 2:
    • Visa PayWave MSD + qVSDC
    • MasterCard PayPass Mag Stripe
  • Magnetic Stripe Card – ISO7811, Track 1 + Track 2
  • Other Cards Supported: NFC, MIFARE, HID-iClass
  • Support of Payment Applications – Global and Local Environment
Standards
  • ISO 7816 Contact Smart Card, approved by EMVco
  • ISO 14443 Type A and B, approved by EMVco
  • ISO 15693
Storage Conditions
  • Temperature  –  -40°C – 60°C  –  -40°F – 140°F
  • Humidity  –  5% – 95% (non-condensing)



Technical Information
  • Interface communication – RS232 up to 115,200 kbps
  • 2 X 16 Character LCD display + 4 LEDs + Buzzer + Speaker
  • Transaction start/end button
  • Power Supply: 8 Volt DC – 16 Volt DC
  • Security – Support of DES, 3DES, AES, RSA, SHA1 algorithms
  • On-board SAM: EMV/HID support
  • RF contactless Interface: Frequency – 13.56 MHz, MIFARE, NFC, HID
Regulatory Compliance
  • EMVco Level 1 + Level 2
  • CE + FCC + RoHS
Operating Conditions
  • Temperature  –  -30°C – 50°C  –  -22°F – 122°F
  • Humidity  –  5% – 95% (non-condensing)
Weight 4 kg
Dimensions 4.31 × 3.31 × 3.31 in
